Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta HOPE BHZ II 00 - a 285.74 6.99 ISC HOPE VNAC3 SHZ AW -- + a 159.01 16.11 ISC VNA2 SNAA B?Z IR C 156.81 17.62 MOS SNAA EFI BHZ II 00 + a 270.69 19.88 ISC EFI PMSA BHZ IU 10 + a 230.79 20.40 ISC PMSA PMSA BHZ IU 00 + a 230.79 20.40 ISC PMSA MG01 HHZ C1 -- - a 256.22 23.75 ISC MG01 MG01 BHZ C1 -- + a 256.22 23.75 ISC MG01 QSPA BHZ IU 80 + a 179.98 33.51 ISC QSPA QSPA BHZ IU 70 + a 179.98 33.51 ISC QSPA QSPA BHZ IU 60 + a 179.98 33.51 ISC QSPA QSPA BHZ IU 00 + a 179.98 33.51 ISC QSPA CPUP BHZ GT 00 + a 309.03 38.20 ISC CPUP CPUP BHZ GT 00 + a 309.03 38.20 ISC CPUP MAW BHZ AU -- - a 142.39 38.86 ISC MAW ZON HHZ WA -- + a 291.13 39.24 ISC ZON SUR BHZ II 00 - a 71.86 39.65 ISC SUR SUR BHZ II 10 + a 71.86 39.65 ISC SUR AC05 HHZ C1 -- + a 291.88 42.23 ISC AC05 AC05 BHZ C1 -- + a 291.88 42.23 ISC AC05 LCO BHZ IU 00 + a 291.28 42.31 ISC LCO LCO BHZ IU 10 + a 291.28 42.31 ISC LCO LCO BHZ IU 60 + a 291.28 42.31 ISC LCO GO03 BHZ C -- + a 292.98 43.22 ISC GO03 LVC BHZ IU 00 + a 298.25 46.71 ISC LVC TSUM BHZ IU 10 - a 57.91 48.97 ISC TSUM TSUM BHZ IU 00 - a 57.91 48.97 ISC TSUM LPAZ BHZ GT 00 + a 303.26 51.78 ISC LPAZ CASY BHZ IU 00 + a 159.16 52.84 ISC CASY SAML BHZ IU 10 + a 312.63 56.17 ISC SAML SAML BHZ IU 00 + a 312.63 56.17 ISC SAML LSZ BHZ IU 10 - a 66.33 57.49 ISC LSZ NNA B?Z IR C 296.89 59.66 MOS NNA DBIC BHZ GT 00 + a 22.08 65.31 ISC DBIC OTAV BHZ IU 10 + a 301.83 71.06 ISC OTAV OTAV HHZ IU 10 + a 301.83 71.06 ISC OTAV SDV BHZ IU 10 + a 313.07 75.37 ISC SDV TAU BHZ II 10 - a 174.26 80.51 ISC TAU HDC BHZ G 00 + a 301.43 82.27 ISC HDC JTS BHZ II 10 + a 300.83 82.92 ISC JTS ACON HHZ NU -- - a 301.45 84.49 ISC ACON sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
