Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta ANIL H?Z IR D 279.85 0.11 RSNC ANIL TOLC S?Z IR D 348.05 0.12 RSNC TOLC ORTC H?Z IR D 174.85 0.56 RSNC ORTC GUY2C H?Z IR D 354.78 0.75 RSNC GUY2C PRAC H?Z IR D 151.48 0.86 RSNC PRAC ROSC B?Z IR D 69.40 1.04 RSNC ROSC YOTC H?Z IR C 245.12 1.15 RSNC YOTC NORC H?Z IR D 21.43 1.16 RSNC NORC CBOC H?Z IR D 332.76 1.56 RSNC CBOC VILC S?Z IR C 102.56 1.64 RSNC VILC SPBC H?Z IR D 46.10 1.69 RSNC SPBC HELC H?Z IR D 352.29 1.72 RSNC HELC MARP H?Z IR C 202.12 1.75 RSNC MARP MALC S?Z IR D 257.42 2.08 RSNC MALC PIZC H?Z IR C 283.47 2.11 RSNC PIZC PTBC H?Z IR D 22.12 2.22 RSNC PTBC PCON H?Z IR C 207.31 2.40 RSNC PCON SOTA H?Z IR C 209.46 2.67 RSNC SOTA ZARC H?Z IR D 8.25 3.03 RSNC ZARC BBAC H?Z IR C 218.71 3.12 RSNC BBAC PTGC H?Z IR C 94.80 3.17 RSNC PTGC OCAC H?Z IR C 27.61 4.23 RSNC OCAC CURV BHZ VE -- + a 43.58 7.63 ISC CURV sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
