Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta UGM SHZ GE -- + a 190.80 2.07 ISC UGM XMIS BHZ AU -- + a 228.30 6.94 ISC XMIS PLAI BHZ GE -- - a 113.80 7.42 ISC PLAI KAPI BHZ II 10 - a 84.94 8.84 ISC KAPI KAPI BHZ II 00 - a 84.94 8.84 ISC KAPI WC1 BHZ AU -- - a 123.69 26.71 ISC WC1 WR3 BHZ AU -- + a 123.69 26.77 ISC WR3 WR7 BHZ AU -- - a 123.62 26.84 ISC WR7 WR8 BHZ AU -- - a 123.59 26.86 ISC WR8 CMMT BHZ TM -- - a 334.56 27.21 ISC CMMT CHTO HHZ IU 00 - a 334.56 27.21 ISC CHTO KMI ??? IR c 345.85 31.81 BJI KMI GYA ??? IR c 352.88 32.39 BJI GYA WHN ??? IR c 5.00 36.35 BJI WHN STKA BHZ AU -- - a 135.94 38.62 ISC STKA XAN ??? IR c 357.41 39.73 BJI XAN GTA ??? IR c 348.07 46.20 BJI GTA ULN BHZ IU 00 + a 356.77 53.61 ISC ULN ULN BHZ IU 10 + a 356.77 53.61 ISC ULN MKAR BHZ KZ -- + a 337.23 58.25 ISC MKAR MAKZ BHZ IU 00 - a 337.03 58.38 ISC MAKZ sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
