Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta AS15 SHZ AU -- - a 212.88 21.52 ISC AS15 AS19 SHZ AU -- - a 212.67 21.55 ISC AS19 FITZ BHZ AU -- - a 237.03 23.76 ISC FITZ WRKA BHZ AU -- - a 220.29 25.92 ISC WRKA PSAD2 BHZ AU 00 - a 235.81 30.12 ISC PSAD2 PSAC2 BHZ AU 00 - a 235.96 30.15 ISC PSAC2 PSAD1 BHZ AU 00 - a 236.21 30.16 ISC PSAD1 PSA00 BHZ AU 00 - a 235.99 30.20 ISC PSA00 MEEK BHZ AU -- + a 228.84 33.72 ISC MEEK KSM BHZ MY -- - a 280.13 36.80 ISC KSM WHN ??? IR c 321.46 47.38 BJI WHN KMI ??? IR c 307.75 52.40 BJI KMI CHTO BHZ IU 00 + a 298.69 52.78 ISC CHTO CHTO BHZ IU 10 + a 298.69 52.78 ISC CHTO XAN BHZ IC 00 - a 320.76 53.12 ISC XAN LZH ??? IR d 319.52 57.65 BJI LZH GTA ??? IR c 320.44 62.18 BJI GTA VNDA BHZ GT 00 - a 176.52 72.22 ISC VNDA MKAR BHZ KZ -- + a 320.59 76.94 ISC MKAR ILW BHZ AV -- + a 26.23 80.74 ISC ILW QSPA BHZ IU 60 + a 180.00 84.25 ISC QSPA QSPA BHZ IU 10 + a 180.00 84.25 ISC QSPA CCB BHZ AK -- + a 23.21 85.03 ISC CCB sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
