Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta RK2S SHZ IR + a 231.20 19.25 ISC RK2S MTSU SHZ IR - a 250.96 22.57 ISC MTSU ARMA BHZ IR - a 214.78 23.27 ISC ARMA BKZ HHZ IR - a 164.07 28.64 ISC BKZ INKA BHZ IR + a 233.07 29.09 ISC INKA STKA BHZ IR - a 225.23 30.62 ISC STKA MULG BHZ IR + a 233.64 35.46 ISC MULG KNRA BHZ IR + a 259.56 37.08 ISC KNRA SANI BHZ IR - a 280.29 41.54 ISC SANI PSAB1 BHZ IR - a 251.37 45.85 ISC PSAB1 MEEK BHZ IR + a 244.65 47.53 ISC MEEK KMI ??? IR c 301.22 72.33 BJI KMI CHTO BHZ IR + a 293.77 73.41 ISC CHTO GTA ??? IR d 313.68 80.26 BJI GTA VCNR HHZ IR + a 48.35 85.02 ISC VCNR sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
