Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta CO06 H?Z IR C 315.67 0.15 GUC CO06 CO03 H?Z IR D 94.59 0.71 GUC CO03 GO04 H?Z IR D 45.34 0.86 GUC GO04 LCO BHZ IU 00 - a 21.88 1.90 ISC LCO LCO BHZ IU 60 - a 21.88 1.90 ISC LCO AC02 BHZ C1 -- - a 28.54 4.45 ISC AC02 VA04 HHZ C1 -- - a 243.42 6.83 ISC VA04 LPAZ SHZ GT 10 - a 12.84 14.76 ISC LPAZ LPAZ BHZ GT 00 - a 12.84 14.76 ISC LPAZ PDPR BHZ PR -- - a 6.95 48.81 ISC PDPR SNAA BHZ GE -- + a 158.75 54.40 ISC SNAA R40B BHZ N4 -- + a 342.89 71.40 ISC R40A sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
