Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta LVC HHZ IU 10 - a 250.64 0.23 ISC LVC AF01 H?Z IR D 131.88 0.62 GUC AF01 PB06 H?Z IR C 258.33 0.84 GUC PB06 PB06 HHZ CX -- + a 258.33 0.84 ISC PB06 PB15 H?Z IR C 227.39 0.99 GUC PB15 PB15 HHZ CX -- + a 227.39 0.99 ISC PB15 PB03 H?Z IR C 295.87 1.11 GUC PB03 PB03 HHZ CX -- + a 295.87 1.11 ISC PB03 PB04 H?Z IR C 278.20 1.38 GUC PB04 PB04 HHZ CX -- + a 278.20 1.38 ISC PB04 PB07 H?Z IR C 305.56 1.38 GUC PB07 PB07 HHZ CX -- + a 305.56 1.38 ISC PB07 PB05 H?Z IR C 257.12 1.44 GUC PB05 PB05 HHZ CX -- + a 257.12 1.44 ISC PB05 PB02 H?Z IR C 316.78 1.66 GUC PB02 PB01 H?Z IR C 333.05 1.67 GUC PB01 PB01 HHZ CX -- + a 333.05 1.67 ISC PB01 PB10 H?Z IR C 240.28 1.98 GUC PB10 PB08 H?Z IR C 349.42 2.42 GUC PB08 PB14 H?Z IR C 216.93 2.61 GUC PB14 PB11 H?Z IR C 341.56 2.91 GUC PB11 sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
