Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta LVC B?Z IR D 318.42 2.37 GUC LVC PB15 H?Z IR C 299.34 2.39 GUC PB15 PB06 H?Z IR C 307.40 2.75 GUC PB06 PB14 H?Z IR C 264.94 2.92 GUC PB14 AC02 HHZ C1 -- + a 215.19 2.98 ISC AC02 AC02 BHZ C1 -- + a 215.19 2.98 ISC AC02 PB05 H?Z IR C 298.69 3.15 GUC PB05 PB10 BHZ CX -- - a 285.41 3.19 ISC PB10 PB09 H?Z IR D 323.75 3.20 GUC PB09 PB03 H?Z IR C 314.49 3.31 GUC PB03 PB04 H?Z IR C 306.69 3.40 GUC PB04 PB07 H?Z IR C 316.65 3.63 GUC PB07 PB01 H?Z IR D 327.35 3.95 GUC PB01 GO03 B?Z IR C 219.94 4.19 GUC GO03 PB08 H?Z IR D 336.60 4.61 GUC PB08 AC04 BHZ C1 -- + a 221.82 5.13 ISC AC04 PB11 BHZ CX -- - a 333.35 5.14 ISC PB11 LCO BHZ IU 10 + a 213.47 5.55 ISC LCO LCO BHZ IU 00 + a 213.47 5.55 ISC LCO PB16 BHZ CX -- + a 340.02 6.40 ISC PB16 CO03 BHZ C1 -- - a 204.93 7.12 ISC CO03 CO03 HHZ C1 -- - a 204.93 7.12 ISC CO03 LPAZ SHZ GT 10 - a 353.71 8.12 ISC LPAZ CPUP BHZ GT 00 + a 104.22 9.14 ISC CPUP CPUP BHZ GT 00 + a 104.22 9.14 ISC CPUP SAML BHZ IU 00 + a 14.72 15.84 ISC SAML PET01 HHZ ON -- + a 93.78 18.17 ISC PET01 MAN01 HHZ ON -- - a 90.64 21.35 ISC MAN01 GUA01 HHZ ON -- - a 78.33 26.79 ISC GUA01 RCBR BHZ IU 00 - a 63.54 35.27 ISC RCBR RCBR BHZ IU 10 - a 63.54 35.27 ISC RCBR VNA3 BHZ AW -- - a 160.97 56.84 ISC VNA3 VNA2 BHZ AW -- - a 160.29 57.41 ISC VNA2 SNAA BHZ GE -- - a 160.57 59.04 ISC SNAA BYRD BHZ YT -- - a 189.18 59.88 ISC BYA TROLL BHZ NO -- + a 160.48 60.75 ISC TROLL TUPA HHZ LD -- - a 353.24 64.66 ISC TUPA QSPA HHZ IU 85 - a 180.04 65.81 ISC QSPA QSPA BHZ IU 70 - a 180.04 65.81 ISC QSPA QSPA BHZ IU 60 - a 180.04 65.81 ISC QSPA QSPA BHZ IU 10 - a 180.04 65.81 ISC QSPA MNTX BHZ US 00 + a 324.99 66.66 ISC MNTX DBIC BHZ GT 00 + a 71.49 68.11 ISC DBIC KUKU BHZ AF -- + a 74.22 71.79 ISC KUK sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
