Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta TIPB ??? IR C 154.04 0.04 TAP TIPB NWF ??? IR C 339.87 0.07 TAP NWF TWA ??? IR C 262.37 0.20 TAP TWA NHDH ??? IR C 260.18 0.26 TAP NHDH TWE ??? IR C 203.97 0.31 TAP TWE TWY ??? IR C 324.95 0.33 TAP TWY NWLT ??? IR C 230.33 0.36 TAP NWLT ENTT ??? IR C 210.88 0.43 TAP ENTT NDT ??? IR C 213.55 0.48 TAP NDT NSK ??? IR C 231.07 0.52 TAP NSK NCU ??? IR C 266.31 0.56 TAP NCU NNS ??? IR C 214.98 0.69 TAP NNS HSN ??? IR C 255.11 0.79 TAP HSN LIOB ??? IR C 243.52 0.80 TAP LIOB NSTT ??? IR C 243.04 0.82 TAP NSTT NACB ??? IR C 193.12 0.85 TAP NACB FUSS ??? IR C 214.20 0.91 TAP FUSS TWD ??? IR C 191.77 0.94 TAP TWD WHF ??? IR C 209.97 0.99 TAP WHF WHP ??? IR C 227.32 1.07 TAP WHP CHGB ??? IR C 211.54 1.10 TAP CHGB NSY ??? IR C 238.44 1.12 TAP NSY SMLT ??? IR C 216.61 1.39 TAP SMLT TYC ??? IR C 218.42 1.40 TAP TYC SSLB ??? IR C 212.79 1.44 TAP SSLB WNT ??? IR C 222.52 1.52 TAP WNT CHN5 ??? IR C 216.48 1.74 TAP CHN5 ALS ??? IR C 211.72 1.75 TAP ALS WTP ??? IR C 212.09 2.06 TAP WTP TWK ??? IR C 215.07 2.11 TAP TWK CHN1 ??? IR C 213.04 2.16 TAP CHN1 JOW BHZ JP -- + a 71.25 6.10 ISC JOW sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
