Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta JKG ??? IR D 285.73 0.52 JMA JKG JYTA ??? IR D 197.61 0.57 JMA JYTA INU BHZ G 00 - a 175.12 0.79 ISC INU MAJO BHZ IU 60 + a 67.78 1.09 ISC MAJO MAJO BHZ IU 10 + a 67.78 1.09 ISC MAJO JWT ??? IR D 236.29 1.52 JMA JWT JIE ??? IR D 186.51 1.75 JMA JIE JSD ??? IR C 28.60 2.17 JMA JSD JSD BHZ JP -- + a 28.50 2.17 ISC JSD JWY ??? IR D 210.47 2.21 JMA JWY JTNC ??? IR D 205.75 2.56 JMA JTNC JHS ??? IR D 251.12 3.32 JMA JHS JMM BHZ JP -- + a 59.54 3.53 ISC JMM WB9 BHZ AU -- + a 182.92 55.68 ISC WB9 WB8 BHZ AU -- + a 182.93 55.70 ISC WB8 WB7 BHZ AU -- + a 182.93 55.73 ISC WB7 WB6 BHZ AU -- + a 182.94 55.74 ISC WB6 WB5 BHZ AU -- + a 182.94 55.76 ISC WB5 WB4 BHZ AU -- + a 182.94 55.79 ISC WB4 WB3 BHZ AU -- + a 182.95 55.81 ISC WB3 WC1 BHZ AU -- + a 182.97 55.81 ISC WC1 WC2 BHZ AU -- + a 182.94 55.81 ISC WC2 WRAB BHZ II 10 + a 182.94 55.82 ISC WRAB WB2 BHZ AU -- + a 182.95 55.83 ISC WB2 WR1 BHZ AU -- + a 182.97 55.83 ISC WR1 WR3 BHZ AU -- + a 182.91 55.83 ISC WR3 WR6 BHZ AU -- + a 182.84 55.84 ISC WR6 WC3 BHZ AU -- + a 182.93 55.84 ISC WC3 WB1 BHZ AU -- + a 182.96 55.84 ISC WB1 AS31 BHZ AU -- - a 183.24 59.55 ISC AS31 sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
