Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta AML BHZ KN -- - a 22.78 6.15 ISC AML AML HHZ KN -- - a 22.78 6.15 ISC AML UCH HHZ KN -- - a 27.29 6.52 ISC UCH UCH BHZ KN -- - a 27.29 6.52 ISC UCH KK31 ??? IR c 0.10 6.60 NNC KK31 KKAR BHZ KZ -- - a 0.10 6.60 ISC KKAR EKS2 BHZ KN -- - a 21.35 6.66 ISC EKS2 EKS2 HHZ KN -- - a 21.35 6.66 ISC EKS2 AAK BHZ KN -- - a 25.50 6.87 ISC AAK AAK HHZ KN -- - a 25.50 6.87 ISC AAK AAK BHZ II 10 - a 25.48 6.87 ISC AAK AAK BHZ II 00 - a 25.48 6.87 ISC AAK KBK BHZ KN -- - a 27.81 7.05 ISC KBK KBK HHZ KN -- - a 27.81 7.05 ISC KBK ULHL HHZ KN -- + a 36.00 7.26 ISC ULHL CHM BHZ KN -- - a 25.46 7.28 ISC CHMS CHM HHZ KN -- - a 25.46 7.28 ISC CHMS BOOM BHZ KR -- + a 33.43 7.32 ISC BOOM TKM2 ??? IR d 29.91 7.53 NNC TKM2 TKM2 BHZ KN -- - a 29.91 7.53 ISC TKM2 MDOK ??? IR c 35.09 8.35 NNC MDOK KNDC ??? IR c 34.53 8.36 NNC KNDC PDGK ??? IR d 42.57 9.71 NNC PDGK GYA0B ??? IR d 281.96 9.98 NNC GYA0B OTUK ??? IR c 6.02 11.82 NNC OTUK MAKZ ??? IR c 36.16 13.40 NNC MAKZ AB31 ??? IR c 332.18 14.90 NNC AB31 ABKAR BHZ KZ -- + a 332.18 14.90 ISC ABKAR KURBB ??? IR c 19.77 15.26 NNC KURBB KURK ??? IR c 19.81 15.37 NNC KURK BVA1 ??? IR d 359.77 16.53 NNC BVA1 BRVK ??? IR d 359.55 16.56 NNC BRVK AKTO ??? IR d 331.05 16.59 NNC AKTO ZAA0 ??? IR c 25.19 20.09 NNC ZAA0 sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
