Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta CEP ??? IR - 167.64 2.81 MSSP CEP IUG M?Z IR D 351.21 5.64 MOS IUG IUG ??? IR d 351.21 5.64 SOME IUG AML BHZ KN -- - a 18.51 5.88 ISC AML AML HHZ KN -- - a 18.51 5.88 ISC AML UCH BHZ KN -- - a 23.48 6.21 ISC UCH EKS2 BHZ KN -- - a 17.39 6.40 ISC EKS2 KK31 ??? IR d 355.65 6.54 NNC KK31 AAK BHZ KN -- - a 21.84 6.57 ISC AAK AAK HHZ KN -- + a 21.84 6.57 ISC AAK AAK B?Z IR C 21.82 6.57 MOS AAK AAK BHZ II 00 - a 21.82 6.57 ISC AAK AAK BHZ II 10 - a 21.82 6.57 ISC AAK KBK HHZ KN -- - a 24.37 6.73 ISC KBK KBK BHZ KN -- - a 24.37 6.73 ISC KBK CHMS ??? IR c 22.04 6.98 NNC CHMS TKM2 ??? IR d 26.81 7.19 NNC TKM2 TKM2 BHZ KN -- + a 26.81 7.19 ISC TKM2 TKM2 HHZ KN -- + a 26.81 7.19 ISC TKM2 PDGK ??? IR c 40.80 9.28 NNC PDGK OTUK ??? IR c 3.79 11.70 NNC OTUK MKAR B?Z IR C 35.58 13.14 MOS MKAR BRVK B?Z IR C 358.08 16.50 MOS BRVK AKTO ??? IR d 329.71 16.79 NNC AKTO ARU B?Z IR C 340.75 21.61 MOS ARU YKA B?Z IR C 2.72 81.17 MOS YKA sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
