Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta BARC E?Z IR C 202.73 0.24 RSNC BARC PAMC E?Z IR C 36.60 0.65 RSNC PAMC BRRC H?Z IR C 294.97 0.68 RSNC BRRC TAMC H?Z IR C 106.33 1.34 RSNC TAMC PTBC H?Z IR D 258.60 1.39 RSNC PTBC SPBC H?Z IR D 220.25 1.52 RSNC SPBC CHIC H?Z IR D 196.46 2.27 RSNC CHIC ROSC B?Z IR D 212.03 2.31 RSNC ROSC VILC S?Z IR D 192.67 2.75 RSNC VILC PTGC H?Z IR D 159.90 2.77 RSNC PTGC LL6C H?Z IR D 356.45 2.91 RSNC LL6C DBBC S?Z IR C 273.86 3.11 RSNC DBBC SDV HHZ IU 10 + a 49.66 3.18 ISC SDV SDV BHZ IU 10 + a 49.66 3.18 ISC SDV SDV B?Z IR C 49.64 3.18 RSNC SDV ARGC H?Z IR D 339.31 3.23 RSNC ARGC SJCC H?Z IR D 326.07 3.69 RSNC SJCC CRJC H?Z IR D 2.78 4.18 RSNC CRJC MACC H?Z IR D 189.30 4.70 RSNC MACC BAUV BHZ VE -- + a 66.77 5.43 ISC BAUV POPC H?Z IR C 220.25 5.55 RSNC POPC FLOC H?Z IR D 206.30 5.79 RSNC FLOC sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
