Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta BARC E?Z IR D 190.08 0.25 RSNC BARC BRRC H?Z IR C 294.99 0.63 RSNC BRRC PAMC E?Z IR C 41.26 0.66 RSNC PAMC RUSC H?Z IR D 176.67 0.94 RSNC RUSC PTBC H?Z IR D 257.22 1.34 RSNC PTBC TAMC H?Z IR C 106.65 1.40 RSNC TAMC OCAC H?Z IR C 352.65 1.40 RSNC OCAC OCA BHZ CM 00 + a 352.63 1.40 ISC OCAC ROSC B?Z IR D 210.67 2.31 RSNC ROSC PTGC H?Z IR D 159.09 2.81 RSNC PTGC DBBC S?Z IR C 273.49 3.05 RSNC DBBC ARGC H?Z IR D 340.00 3.19 RSNC ARGC SDV HHZ IU 10 + a 50.54 3.21 ISC SDV SDV BHZ IU 10 + a 50.54 3.21 ISC SDV SDV BHZ IU 00 + a 50.54 3.21 ISC SDV SDV B?Z IR C 50.52 3.21 RSNC SDV GUVC S?Z IR D 173.17 4.30 RSNC GUVC BAUV BHZ VE -- + a 67.19 5.46 ISC BAUV POPC H?Z IR D 219.69 5.54 RSNC POPC SOTA H?Z IR D 216.66 5.81 RSNC SOTA BIRV BHZ VE -- + a 61.51 7.69 ISC BIRV sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
