Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta KBL BHZ IU -- + a 218.22 2.44 ISC KBL NIL BHZ II 10 - a 144.40 3.44 ISC NIL NIL BHZ II 00 - a 144.40 3.44 ISC NIL TAS HHZ CK -- - a 346.26 5.00 ISC TAS IUG M?Z IR D 353.70 5.70 MOS IUG IUG ??? IR d 353.70 5.70 SOME IUG ARLS BHZ KR -- - a 25.51 6.00 ISC ARLS ASAI HHZ KC -- - a 43.17 6.26 ISC ASAI ASAI BHZ KC -- - a 43.17 6.26 ISC ASAI DZA L?Z IR D 3.02 6.42 MOS DZA DZA ??? IR d 3.02 6.42 SOME DZA KK31 ??? IR d 357.72 6.63 NNC KK31 KKAR BHZ KZ -- - a 357.72 6.63 ISC KKAR AAK B?Z IR C 23.34 6.76 MOS AAK AAK BHZ II 10 - a 23.34 6.76 ISC AAK AAK BHZ II 00 - a 23.34 6.76 ISC AAK CHMS ??? IR c 23.45 7.17 NNC CHMS TKM2 ??? IR c 28.05 7.39 NNC TKM2 SGDS M?Z IR D 21.33 7.54 MOS SGDS SGDS ??? IR d 21.33 7.54 SOME SGDS MDOK ??? IR d 33.53 8.20 NNC MDOK BTLS M?Z IR C 14.72 8.89 MOS BTLS BTLS ??? IR c 14.72 8.89 SOME BTLS GYA0B ??? IR c 281.93 10.28 NNC GYA0B MAKZ ??? IR d 35.30 13.23 NNC MAKZ MK31 ??? IR d 36.03 13.37 NNC MK31 MKAR BHZ KZ -- + a 36.03 13.37 ISC MKAR AB31 ??? IR d 331.43 15.05 NNC AB31 ABKAR BHZ KZ -- + a 331.43 15.06 ISC ABKAR KURK B?Z IR C 18.97 15.29 MOS KURK KURK ??? IR c 18.97 15.29 NNC KURK BVA0 ??? IR c 358.98 16.55 NNC BVA0 BRVK B?Z IR C 358.76 16.59 MOS BRVK BRVK ??? IR c 358.76 16.59 NNC BRVK AKTO ??? IR c 330.42 16.75 NNC AKTO ZAA0 ??? IR d 24.64 19.98 NNC ZAA0 ARU B?Z IR C 341.25 21.62 MOS ARU KIRV B?Z IR C 334.30 26.22 MOS KIRV NRIK B?Z IR C 10.45 34.17 MOS NRIK YAK B?Z IR C 35.46 44.05 MOS YAK NC303 BHZ NO 00 - a 323.33 44.28 ISC NC303 NB201 BHZ NO 00 + a 323.08 44.30 ISC NB201 NC204 BHZ NO 00 - a 323.37 44.58 ISC NC204 MEM SHZ IR - 308.63 47.60 UCC MEM BMRD SHZ IR - 308.40 48.43 UCC BMRD YKA B?Z IR C 2.57 81.27 MOS YKA sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
