Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta SPBC H?Z IR C 77.39 0.27 RSNC SPBC NORC H?Z IR C 266.89 0.53 RSNC NORC ROSC B?Z IR C 178.74 0.75 RSNC ROSC GUY2C H?Z IR C 250.36 1.09 RSNC GUY2C HELC H?Z IR C 296.67 1.33 RSNC HELC BARC E?Z IR D 49.07 1.52 RSNC BARC ANIL H?Z IR D 224.20 1.52 RSNC ANIL BRRC H?Z IR D 22.39 1.63 RSNC BRRC PRAC H?Z IR D 196.38 1.94 RSNC PRAC ZARC H?Z IR D 344.67 1.96 RSNC ZARC DBBC E?Z IR D 307.34 2.34 RSNC DBBC UREC H?Z IR D 331.08 2.45 RSNC UREC PTGC H?Z IR D 122.15 2.59 RSNC PTGC MACC H?Z IR D 171.88 3.46 RSNC MACC GUVC E?Z IR C 150.55 3.48 RSNC GUVC GARC H?Z IR C 198.88 3.58 RSNC GARC LCBC H?Z IR C 328.26 3.82 RSNC LCBC POPC H?Z IR D 217.67 3.83 RSNC POPC FLOC H?Z IR D 198.30 4.19 RSNC FLOC SJCC H?Z IR D 349.00 4.36 RSNC SJCC SDV BHZ IU 10 + a 48.11 4.92 ISC SDV sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
