Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta BARC E?Z IR D 189.94 0.24 RSNC BARC BRRC H?Z IR C 295.93 0.63 RSNC BRRC PAMC E?Z IR C 40.83 0.67 RSNC PAMC RUSC H?Z IR D 176.49 0.93 RSNC RUSC PTBC H?Z IR D 257.62 1.34 RSNC PTBC TAMC H?Z IR C 106.22 1.40 RSNC TAMC NORC H?Z IR C 233.88 2.13 RSNC NORC CHIC H?Z IR D 195.09 2.26 RSNC CHIC ROSC B?Z IR D 210.75 2.30 RSNC ROSC GUY2C H?Z IR C 234.32 2.73 RSNC GUY2C VILC E?Z IR D 191.55 2.76 RSNC VILC PTGC H?Z IR D 158.97 2.80 RSNC PTGC CBOC H?Z IR C 251.57 3.01 RSNC CBOC SDV BHZ IU 10 + a 50.43 3.21 ISC SDV SDV HHZ IU 10 + a 50.43 3.21 ISC SDV ORTC H?Z IR C 215.95 3.58 RSNC ORTC SJCC H?Z IR D 326.63 3.65 RSNC SJCC PLMC H?Z IR C 238.71 3.66 RSNC PLMC CRJC H?Z IR C 3.49 4.17 RSNC CRJC YOTC H?Z IR D 228.61 4.26 RSNC YOTC GUVC E?Z IR C 173.12 4.29 RSNC GUVC MACC H?Z IR D 188.64 4.71 RSNC MACC MALC E?Z IR D 236.38 5.03 RSNC MALC sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
