Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta IST3 HHZ IR - m 208.82 0.42 ROM IST3 CET2 HHZ IR - m 44.79 0.51 ROM CET2 CAR1 HHZ IR - m 80.91 0.57 ROM CAR1 JOPP HHZ IR - m 150.79 0.64 ROM JOPP GRI EHZ IR + m 114.99 0.80 ROM GRI TDS HHZ IR - m 52.93 0.82 ROM TDS CUC HHE IR - m 16.93 0.86 ROM CUC MSRU HHZ IR - m 178.94 0.90 ROM MSRU CEL HHZ IR - m 160.53 0.96 ROM CEL MGR HHZ IR - m 2.97 0.97 ROM MGR SALB HHZ IR - m 42.77 0.97 ROM SALB SIRI HHZ IR - m 15.98 1.06 ROM SIRI SCHR EHZ IR - m 23.54 1.13 ROM SCHR ORI HHZ IR - m 39.32 1.16 ROM ORI LADO EHZ IR - m 83.71 1.17 ROM LADO PTRP HHZ IR + m 17.87 1.42 ROM PTRP PLLN EHZ IR - m 222.38 1.58 ROM PLLN GIB HHZ IR - m 224.74 1.64 ROM GIB ACER HHZ IR + m 12.04 1.66 ROM ACER PETRA HHZ IR - m 219.44 1.71 ROM PETRA CAGR HHZ IR - m 207.04 1.73 ROM CAGR LTRZ EHZ IR - m 35.08 1.76 ROM LTRZ NOCI HHZ IR - m 36.27 2.02 ROM NOCI RAFF HHZ IR - m 204.91 2.13 ROM RAFF PIGN HNE IR + m 334.18 2.27 ROM PIGN HMDC HHZ IR - m 194.41 2.27 ROM HMDC MODR HHE IR + m 328.56 2.33 ROM MODR SCTE HHZ IR - m 67.58 2.47 ROM SCTE sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
