Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta PLMC H?Z IR C 353.50 0.10 RSNC PLMC YOTC H?Z IR D 185.18 0.82 RSNC YOTC ANIL H?Z IR C 109.67 0.92 RSNC ANIL CBOC H?Z IR D 13.74 1.08 RSNC CBOC PIZC H?Z IR C 278.49 1.10 RSNC PIZC MALC E?Z IR C 233.56 1.32 RSNC MALC ORTC H?Z IR D 130.94 1.35 RSNC ORTC HELC H?Z IR D 28.15 1.56 RSNC HELC JAMC H?Z IR D 194.29 1.63 RSNC JAMC ROSC B?Z IR C 88.83 1.94 RSNC ROSC POPC H?Z IR D 190.20 2.28 RSNC POPC SPBC H?Z IR C 68.84 2.35 RSNC SPBC PTBC H?Z IR D 46.23 2.50 RSNC PTBC CHIC H?Z IR C 93.79 2.54 RSNC CHIC GARC H?Z IR D 163.34 2.71 RSNC GARC ZARC H?Z IR D 27.67 3.02 RSNC ZARC FLOC H?Z IR D 169.06 3.26 RSNC FLOC MACC H?Z IR D 137.42 3.58 RSNC MACC PTGC H?Z IR C 98.11 4.17 RSNC PTGC PTLC H?Z IR D 162.21 4.83 RSNC PTLC BCIP B?Z IR D 320.96 5.60 RSNC BCIP sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
