Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta BO03 H?Z IR C 359.25 0.63 GUC BO03 ML02 H?Z IR C 145.65 0.77 GUC ML02 ML02 BHZ C1 -- - a 145.66 0.77 ISC ML02 ML02 HHZ C1 -- - a 145.66 0.77 ISC ML02 BO02 H?Z IR D 71.13 1.02 GUC BO02 BO01 H?Z IR D 44.41 1.02 GUC BO01 MT01 H?Z IR C 24.84 1.39 GUC MT01 MT01 BHZ C1 -- + a 24.84 1.39 ISC MT01 MT01 HHZ C1 -- - a 24.84 1.39 ISC MT01 VA05 H?Z IR C 10.85 1.49 GUC VA05 VA05 BHZ C1 -- + a 10.85 1.49 ISC VA05 VA05 HHZ C1 -- + a 10.85 1.49 ISC VA05 MT09 BHZ C1 -- + a 30.81 1.56 ISC MT09 MT09 HHZ C1 -- + a 30.81 1.56 ISC MT09 MT09 H?Z IR C 30.80 1.57 GUC MT09 BO04 H?Z IR D 44.65 1.59 GUC BO04 MT12 H?Z IR C 40.19 1.81 GUC MT12 LMEL BHZ C -- - a 48.93 1.93 ISC LMEL LMEL HHZ C -- - a 48.93 1.93 ISC LMEL LMEL H?Z IR D 49.00 1.93 GUC LMEL MT13 H?Z IR C 45.38 1.95 GUC MT13 MT13 BHZ C1 -- - a 45.37 1.95 ISC MT13 MT02 H?Z IR C 20.11 1.98 GUC MT02 MT02 BHZ C1 -- + a 20.11 1.98 ISC MT02 MT02 HHZ C1 -- + a 20.11 1.98 ISC MT02 MT05 H?Z IR C 30.46 2.00 GUC MT05 MT05 HHZ C1 -- + a 30.46 2.00 ISC MT05 MT05 BHZ C1 -- + a 30.46 2.00 ISC MT05 PEL B?Z IR C 28.30 2.24 GUC PEL PEL BHZ G 00 + a 28.50 2.25 ISC PEL FCH H?Z IR C 37.92 2.26 GUC FCH MT04 H?Z IR C 41.67 2.28 GUC MT04 MT07 BHZ C1 -- + a 20.16 2.28 ISC MT07 ROCH H?Z IR C 20.21 2.29 GUC ROCH VA03 BHZ C1 -- + a 26.66 2.63 ISC VA03 VA03 HHZ C1 -- + a 26.66 2.63 ISC VA03 CO02 HHZ C1 -- + a 11.78 3.99 ISC CO02 CO02 BHZ C1 -- - a 11.78 3.99 ISC CO02 CO03 HHZ C1 -- + a 14.27 4.41 ISC CO03 CO03 BHZ C1 -- + a 14.27 4.41 ISC CO03 ZON HHZ WA -- + a 38.34 4.50 ISC ZON GO04 BHZ C -- + a 11.44 5.04 ISC GO04 CO01 HHZ C1 -- + a 17.49 5.37 ISC CO01 CO01 BHZ C1 -- - a 17.49 5.37 ISC CO01 LCO BHZ IU 60 - a 10.21 6.19 ISC LCO LCO BHZ IU 10 - a 10.21 6.19 ISC LCO GO03 BHZ C -- + a 11.52 7.65 ISC GO03 TRQA HHZ IU 10 - a 112.93 8.54 ISC TRQA LPAZ SHZ GT 10 + a 11.29 19.07 ISC LPAZ LPAZ BHZ GT 00 + a 11.29 19.07 ISC LPAZ PCMB HHZ BL -- + a 58.87 22.59 ISC PCMB ETMB HHZ BR -- + a 13.12 25.73 ISC ETMB TBTG HHZ BR -- - a 3.98 30.85 ISC TBTG TEFE HHZ BR -- + a 13.81 32.19 ISC TEFE NAN01 HHZ ON -- + a 66.93 33.09 ISC NAN01 SDBA HHZ BR -- - a 53.95 33.33 ISC SDBA GUA01 HHZ ON -- + a 65.50 34.11 ISC GUA01 GDU01 HHZ ON -- - a 61.98 36.12 ISC GDU01 RUS BHZ CM 00 + a 358.28 40.81 ISC RUSC VNA3 BHZ IR c 157.44 48.29 AWI VNA3 VNA3 BHZ AW -- + a 157.44 48.29 ISC VNA3 VNA1 BHZ IR c 156.53 48.61 AWI VNA1 VNA2 BHZ IR c 156.82 48.95 AWI VNA2 VNA2 BHZ AW -- + a 156.81 48.95 ISC VNA2 SNAA BHZ IR c 157.48 50.52 AWI SNAA TROLL BHZ IR c 157.74 52.22 AWI TROLL QSPA HHZ IU 85 - a 180.05 55.11 ISC QSPA WVT BHZ IU 00 + a 346.56 72.42 ISC WVT LCAR HHZ AG 00 + a 343.82 73.06 ISC LCAR R40B BHZ N4 -- - a 343.60 75.44 ISC R40A N38B BHZ N4 -- + a 343.64 78.05 ISC N38A HWUT BHZ US 00 + a 331.29 84.57 ISC HWUT sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
