Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta CN2S SHZ AU 00 - a 278.00 22.32 ISC CN2S CN1H SHZ AU 00 - a 278.27 22.36 ISC CN1H QLP BHZ AU -- + a 252.93 22.99 ISC QLP MTSU SHZ AU -- - a 274.35 23.34 ISC MTSU STKA B?Z IR C 241.61 26.31 MOS STKA OOD BHZ AU -- - a 251.87 30.68 ISC OOD PSAD1 BHZ AU 00 + a 260.82 45.45 ISC PSAD1 MBWA BHZ IU 10 + a 261.21 45.59 ISC MBWA MEEK BHZ AU -- + a 253.47 45.88 ISC MEEK SANI BHZ GE -- - a 289.15 46.05 ISC SANI TOLI2 BHZ GE -- - a 289.50 52.12 ISC TOLI2 CASY BHZ IU 10 - a 204.03 57.74 ISC CASY CCD BHZ G 00 - a 192.52 58.43 ISC CCD BBJI BHZ GE -- + a 273.65 60.57 ISC BBJI MAJO B?Z IR D 333.00 64.77 MOS MAJO VLA S?Z IR C 332.56 72.93 MOS VLA USA0B B?Z IR D 333.28 73.77 MOS USA0B LYN ??? IR c 315.22 77.46 BJI LYN GRNR S?Z IR D 339.58 77.63 MOS GRNR HNS ??? IR c 318.66 77.81 BJI HNS KLR B?Z IR D 336.14 77.97 MOS KLR KMI ??? IR d 302.47 79.29 BJI KMI XAN ??? IR c 313.03 79.52 BJI XAN ELIB BHZ IR - 190.23 83.67 UCC ELIB LZH ??? IR c 312.43 84.12 BJI LZH SEY S?Z IR C 352.51 85.36 MOS SEY TROLL BHZ IR d 184.22 86.06 AWI TROLL SNAA BHZ IR d 182.62 86.70 AWI SNAA VNA3 BHZ IR d 180.47 87.30 AWI VNA3 VNA3 BHZ AW -- - a 180.47 87.30 ISC VNA3 VNA2 BHZ IR d 181.23 87.58 AWI VNA2 VNA2 BHZ AW -- - a 181.23 87.59 ISC VNA2 VNA1 BHZ IR d 180.96 87.88 AWI VNA1 GTA ??? IR d 313.63 88.57 BJI GTA ULN BHZ IU 00 + a 323.58 88.63 ISC ULN ULN B?Z IR D 323.58 88.63 MOS ULN MONP2 BHZ AZ -- - a 54.25 89.56 ISC MONP2 PFO B?Z IR C 53.59 89.85 MOS PFO sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
