Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta YOTC H?Z IR C 307.01 0.30 RSNC YOTC JAMC H?Z IR C 224.01 0.81 RSNC JAMC ORTC H?Z IR D 83.04 0.87 RSNC ORTC PLMC H?Z IR D 350.94 1.11 RSNC PLMC PRAC H?Z IR D 94.15 1.22 RSNC PRAC MALC E?Z IR C 279.67 1.24 RSNC MALC POPC H?Z IR C 204.34 1.38 RSNC POPC GUY2C H?Z IR D 27.66 1.59 RSNC GUY2C PIZC H?Z IR C 312.77 1.70 RSNC PIZC GARC H?Z IR D 159.07 1.72 RSNC GARC CBOC H?Z IR D 2.66 2.05 RSNC CBOC ROSC B?Z IR D 59.93 2.06 RSNC ROSC BBAC H?Z IR D 212.76 2.10 RSNC BBAC NORC H?Z IR D 35.18 2.14 RSNC NORC GR1C E?Z IR C 248.90 2.20 RSNC GR1C FLOC H?Z IR D 168.35 2.25 RSNC FLOC CHIC H?Z IR D 70.82 2.51 RSNC CHIC GCUF H?Z IR D 205.80 2.84 RSNC GCUF PTBC H?Z IR D 31.11 3.18 RSNC PTBC RUSC H?Z IR D 55.33 3.66 RSNC RUSC PTAC H?Z IR D 333.06 3.73 UPA PTAC PTAC H?Z IR D 333.06 3.73 RSNC PTAC PTLC H?Z IR D 160.03 3.84 RSNC PTLC ZARC H?Z IR D 18.69 3.87 RSNC ZARC BRRC H?Z IR D 35.90 4.06 RSNC BRRC TOTI H?Z IR D 336.85 5.54 UPA TOTI SDV BHZ IU 10 + a 46.88 7.42 ISC SDV CURV BHZ VE -- - a 44.36 8.68 ISC CURV sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
