Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta RMQ SHZ AU -- + a 230.02 21.67 ISC RMQ MRZ HHZ NZ 10 + a 166.38 28.22 ISC MRZ KHZ HHZ NZ 10 + a 170.39 29.52 ISC KHZ WB9 BHZ AU -- - a 253.97 32.03 ISC WB9 WB6 BHZ AU -- + a 253.85 32.05 ISC WB6 WB5 BHZ AU -- - a 253.81 32.06 ISC WB5 WB4 BHZ AU -- - a 253.76 32.07 ISC WB4 WB1 BHZ AU -- + a 253.66 32.09 ISC WB1 WC1 BHZ AU -- - a 253.73 32.09 ISC WC1 WRKA BHZ AU -- + a 246.45 38.38 ISC WRKA PSAA1 BHZ AU 00 + a 252.82 45.74 ISC PSAA1 PSAD1 BHZ AU 00 + a 252.99 45.74 ISC PSAD1 PSAB1 BHZ AU 00 + a 252.83 45.76 ISC PSAB1 PSAC1 BHZ AU 00 + a 252.88 45.77 ISC PSAC1 PSAD3 BHZ AU 00 + a 252.73 45.80 ISC PSAD3 MBWA BHZ IU 10 - a 253.41 45.83 ISC MBWA CASY BHZ IU 10 + a 201.93 64.79 ISC CASY BNX ??? IR c 331.30 68.85 BJI BNX KMI ??? IR d 301.48 73.48 BJI KMI N14K BHZ TA -- + a 15.50 77.18 ISC N14K Q17K BHZ TA -- + a 19.00 77.47 ISC CNTC M14K BHZ TA -- + a 14.94 77.82 ISC M14K O16K BHZ TA -- - a 17.25 77.89 ISC O16K P17K BHZ TA -- - a 18.19 78.05 ISC P17K Q18K BHZ TA -- + a 19.13 78.06 ISC KAHC M15K BHZ TA -- + a 15.52 78.10 ISC M15K L14K BHZ TA -- + a 14.33 78.15 ISC L14K K13K BHZ TA -- + a 13.19 78.22 ISC K13K O17K BHZ TA -- - a 17.57 78.33 ISC O17K N16K BHZ TA -- + a 16.45 78.43 ISC N16K M16K BHZ TA -- + a 16.06 78.83 ISC M16K J14K BHZ TA -- - a 13.25 79.18 ISC J14K K15K BHZ TA -- + a 14.31 79.25 ISC K15K L18K BHZ TA -- - a 16.28 80.44 ISC L18K ULN BHZ IU 00 + a 323.76 80.94 ISC ULN ULN BHZ IU 10 + a 323.76 80.94 ISC ULN L20K BHZ TA -- - a 17.18 81.43 ISC L20K J18K BHZ TA -- + a 15.53 81.45 ISC J18K SCM BHZ AK -- - a 19.94 82.98 ISC SCM WAT7 BHZ AK -- + a 18.73 83.21 ISC WAT7 TRF BHZ AK -- + a 17.82 83.23 ISC TRF WAT1 HHZ AK -- + a 18.83 83.30 ISC WAT1 G19K BHZ TA -- - a 13.84 83.55 ISC G19K RND BHZ AK -- + a 18.33 83.63 ISC RND N25K BHZ TA -- - a 21.02 83.75 ISC N25K MCK BHZ AK -- - a 18.08 83.85 ISC MCK GLB BHZ AK -- - a 21.40 83.91 ISC GLB H22K BHZ TA -- + a 15.85 84.78 ISC H22K CCB BHZ AK -- + a 17.81 84.86 ISC CCB HDA BHZ AK -- + a 18.25 84.94 ISC HDA J25K BHZ TA -- + a 18.58 85.57 ISC J25K F22K BHZ TA -- - a 14.56 85.82 ISC F22K TOLK BHZ TA -- - a 14.56 87.32 ISC TOLK TROLL BHZ IR c 184.74 94.25 AWI TROLL SNAA BHZ IR c 183.16 94.95 AWI SNAA VNA3 BHZ IR c 181.03 95.62 AWI VNA3 VNA1 BHZ IR c 181.53 96.18 AWI VNA1 sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
