Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta BI02 BHZ C1 -- + a 99.02 21.03 ISC BI02 GO04 BHZ C -- - a 82.52 23.04 ISC GO04 LCO BHZ IU 60 + a 79.92 23.58 ISC LCO AC02 BHZ C1 -- + a 76.76 25.79 ISC AC02 GO02 BHZ C -- + a 72.99 26.26 ISC GO02 TA01 BHZ C1 -- + a 64.17 28.46 ISC TA01 PB12 BHZ CX -- + a 60.94 29.62 ISC PB12 EFI B?Z IR C 131.52 31.83 MOS EFI ITRB HHZ BL -- + a 81.23 44.26 ISC ITRB ARAG HHZ BR -- + a 75.44 45.33 ISC ARAG RUS BHZ CM 00 + a 33.67 47.70 ISC RUSC SJMB HHZ BL -- + a 86.22 52.16 ISC SJMB RIB01 HHZ ON -- + a 87.37 52.48 ISC RIB01 SDBA HHZ BR -- + a 77.14 52.68 ISC SDBA URI BHZ CM 00 + a 31.62 53.36 ISC URIC VNA3 BHZ IR d 156.90 55.47 AWI VNA3 VNA1 BHZ IR d 156.31 56.05 AWI VNA1 VNA2 BHZ IR d 156.71 56.26 AWI VNA2 SNAA BHZ IR d 158.04 57.48 AWI SNAA SNAA B?Z IR C 158.04 57.48 MOS SNAA TROLL BHZ IR d 159.07 58.96 AWI TROLL ELIB BHZ IR - 162.74 64.54 UCC ELIB OUENC BHZ ND 00 - a 248.59 81.47 ISC OUENC PNPO HHZ CN -- - a 7.40 85.02 ISC PNPO sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
