Black dots -> compressions (C,c,+,U,u) White dots -> dilatations (D,d,-) Green dot -> T-axis Red dot -> P-axis
sta chan net loc pol a/m azi dist author irsta JNA ??? IR D 152.58 0.27 JMA JNA JKD ??? IR D 304.16 0.46 JMA JKD UWA2 ??? IR D 157.00 0.63 JMA UWA2 JMN BHZ JP -- + a 92.48 1.29 ISC JMN JTU BHZ JP -- + a 287.49 2.54 ISC JTU NAWB BHZ KS -- + a 293.09 4.38 ISC NAWB JGF BHZ JP -- + a 65.06 4.51 ISC JGF CHJ2 BHZ KS -- - a 311.99 4.70 ISC KSCHJ HNS ??? IR c 289.08 14.78 BJI HNS H19K BHZ TA -- - a 30.01 52.05 ISC H19K J19K BHZ AK -- + a 31.96 52.40 ISC J19K K20K BHZ AK -- - a 32.73 53.12 ISC K20K WB9 BHZ AU -- + a 177.59 53.32 ISC WB9 WR5 BHZ AU -- + a 177.54 53.48 ISC WR5 WC3 BHZ AU -- - a 177.61 53.49 ISC WC3 WC4 BHZ AU -- + a 177.65 53.49 ISC WC4 L22K BHZ TA -- + a 33.61 54.69 ISC L22K H23K BHZ AK -- - a 29.51 54.89 ISC H23K E24K BHZ TA -- - a 26.72 55.12 ISC E24K SCRK BHZ AK -- + a 31.32 57.50 ISC SCRK I28M BHZ TA -- - a 29.19 58.88 ISC I28M G30M BHZ TA -- - a 27.01 59.95 ISC G30M I30M BHZ TA -- + a 28.99 60.38 ISC I30M BUR31 BHZ RO -- + a 318.24 75.99 ISC BUR08 DLMT BHZ IW 00 - a 40.19 81.73 ISC DLMT UCC BHZ IR - 329.81 84.10 UCC UCC WLF BHZ IR - 328.18 84.18 UCC WLF BMRD BHZ IR - 329.28 84.30 UCC BMRD PSUT HHZ UU 01 + a 46.04 85.42 ISC PSUT SRU BHZ UU 01 + a 43.89 87.00 ISC SRU sta - Station code (FDSN) chan - channel code net - Network code (FDSN) loc - Location code (FDSN) pol - Polarity a/m - Automatic or manual pick azi - Event to station azimuth (in degrees) dist - Event to station distance (in degrees) author - Author of the polarity irsta - International registry station code
